article no.: 30285

550 kg/h ; 1120 °C Continuous oven, drying oven

Fa. Mahler und Kühler Fa. Günter

Description

Description

producer: Fa. Mahler und Kühler Fa. Günter
type designation:
condition: used
Width 800 mm conveyor belt width
Height 220 mm Clear height above belt
Length 3000 mm Useful oven length heated
Temperature 1140 °C Upper limit temperature
– 850 – 1120 °C working temperature
Power 170 kW Heat output
Dimensions 21000 x 3000 mm approx. length x width
Power 550 kg/h Gross throughput capacity
Further information 3 Temperature control groups
– Conveyor belt control range 50 – 500 mm/min
Weight 15600 kg approx.

thermical proceeding
